Gateway
The Highest Density DSP-based 1RU IP Audio Codec
The Tieline Gateway is the most powerful DSP-based 1RU IP codec enabling transport of multiple channels of mono or stereo audio across the public internet and any QoS-enabled IP network, including T1 and T3 connections and private WANs with MPLS. The Gateway streams up to 16 IP audio channels and speaks the language of AES67, ST 2110-30, ST 2022-7, RAVENNA, Livewire+, NMOS, Ember+, AES3 and analog I/O as standard. An optional WheatNet-IP or Dante card can also be installed at purchase.
NAB Show Product of the Year
The Gateway has won the prestigious NAB Show Product of the Year Award 2020
IBC Best of Show Award Winner
The Gateway has won the prestigious IBC Best of Show Award 2019
IBC Best of Show Award Winner
The Gateway has won the RedTech Tribe Choice Award presented during the 2021 RedTech Radio Week, in collaboration with French publication La Lettre Pro de la Radio
watch the video
Introducing the Gateway Multichannel IP Audio Codec
Overview
The Most powerful DSP-based 1RU IP Codec
The Tieline Gateway introduces a new era in high-density multichannel IP codec streaming. The Gateway supports up to 16 mono channels or 8 stereo streams of bidirectional IP audio in 1RU to increase efficiency and reduce rack space requirements. It interfaces easily with legacy analog and AES/EBU digital sources, as well as newer broadcast plants with AES67, ST 2110-30, ST 2022-7, Livewire+, RAVENNA, NMOS, and Ember+. An optional WheatNet-IP card is also available.
The Gateway is perfect for large-scale audio distribution to single or multiple locations, as well as managing multiple incoming remotes at the studio using SmartStream PLUS redundant IP streaming and Fuse-IP data aggregation technologies over internet connections. It is interoperable with all Tieline IP codecs and compatible over SIP with all EBU N/ACIP Tech 3326, 3347 and 3368 compliant codecs and devices.
Features at a Glance
Analog, AES3
Support for AES67, plus AES3 (AES/EBU)
and analog I/O options.
HTTP Streaming
Support for Icecast or Shoutcast HTTP streaming
SIP and IP Intercoms
SIP EBU Tech 3326, 3368, and EBU Tech 3347
Dual AoIP Ports
Stream AoIP from dual ports
SD card
SD card slot for firmware upgrades, storage and SDIO
Alarms
Silence Detection, PSU Failure, Lost connection, Temperature, AES Input, AES Reference, SNMP and more
Dual Internal Power Supplies
Dual power supplies provide backup if one fails
Dual Ethernet Ports
Connect using different Telcos for diversity using SmartStream PLUS redundant streaming
Module Compatible*
Module slot for future hardware innovations
Multi-Unicast
Support for multiple simultaneous multi-unicasts over compatible IP networks to up to 80 endpoints
Simultaneous Multicast
Support for multiple simultaneous multicasts over compatible IP networks to unlimited endpoints
Phase-locked streaming mode
Up to 8 channels of digital phase-locked multichannel audio, including 6 channel (5.1 or 6.0), 8 channel (7.1 or 8.0), and 4 channel phase-locked surround sound streams.
Internal SSD Storage
Internal Storage supports record, store and forward use cases for network syndication applications*
Expanded Backup Options
Multiple levels of power, audio and network redundancy. The codec features dual Gigabit Ethernet ports, dual internal power supplies, automated audio silence detection and IP network backup solutions to ensure you’re always on the air.
AoIP Interfaces
AES67 Ready
Native support out-of-the-box so forget hardware card upgrades, just connect and go!
ST 2110-30 & ST 2022-7
SMPTE ST 2110-30 and ST 2022-7 compliant out-of-the-box
WheatNet-IP
Purchase with an optional WheatNet-IP card for interoperability with WheatNet-IP networks
Note: Optional at time of Purchase
Dante
Purchase with an optional Dante card for interoperability with the Dante networks
Note: Optional at time of Purchase
Livewire+
Native support lets you connect directly to Livewire+ AES67 networks and exchange audio streams.
RAVENNA
Native support for RAVENNA, an open technology for stream discovery and advertisement.
NMOS
AMWA NMOS IS-04 and IS-05 provides discovery, registration, and control for ST 2110 AoIP streaming, delivering a new level of interoperability and control with networked equipment throughout the broadcast plant.
Ember+
The Ember+ control protocol is supported
* Denotes future release
Models Available
Gateway
8 Channel base model-
8 Channels (8 Mono or 4 Stereo)
-
DSP Powered
-
Native support for AES67, SMPTE ST 2110-30, ST 2022-7, Livewire+ and RAVENNA
-
Analog and AES3 I/O
-
SIP EBU N/ACIP 3326 & 3368
-
EBU Tech 3347 for IP Intercom
-
2, 4 or 8 Channel and Streaming license upgrades as required
-
WheatNet-IP card (optional)
Gateway
16 Channel model-
16 Channels (16 Mono or 8 Stereo)
-
DSP Powered
-
Native support for AES67, SMPTE ST 2110-30, ST 2022-7, Livewire+ and RAVENNA
-
Analog and AES3 I/O
-
SIP EBU N/ACIP 3326 & 3368
-
EBU Tech 3347 for IP Intercom
-
WheatNet-IP card (optional)
Optional Upgrades
WheatNet-IP
Purchase with an optional WheatNet-IP card for interoperability with WheatNet-IP networks
Note: Optional at time of Purchase
Dante
Purchase with an optional Dante card for interoperability with Dante networks
Note: Optional at time of Purchase
2 Channel Upgrade
License the 8 channel Gateway base model with 2 additional channels in/out and stream capacity
4 Channel Upgrade
License the 8 channel Gateway base model with 4 additional channels in/out and stream capacity
8 Channel Upgrade
License the 8 channel Gateway base model with 8 additional channels in/out and stream capacity
Optional Internal ISDN Module
Purchase an optional Euro ISDN module for compatibility over ISDN networks.
Flexible Audio Distribution
The Gateway supports 16 mono or 8 stereo full-duplex audio streams. Gateway also supports flexible multi-unicasting and multicasting configurations for audio distribution.
- Stream up to 16 different multi-unicast audio streams to up to 80 endpoints in total.
- Stream up to 16 different multicast audio streams to unlimited endpoints over compatible networks
SmartStream PLUS redundant streaming
Connect multiple IP links to codecs and use SmartStream PLUS to stream simultaneous redundant data streams and deliver seamless redundancy when streaming over IP.
Bond multiple interfaces with Fuse-IP
Imagine the peace of mind knowing you can bond data links from different Telcos and let Tieline’s Fuse-IP technology automatically manage the data capability of each link!
Applications
Perfect for STL, SSL and audio distribution applications, with support for multicasting and multiple unicasting technologies. It is also perfect for managing multiple incoming remotes at the studio and can simultaneously connect to up to 16 hardware codecs or Report-IT Enterprise smartphone app users.
- Studio-To-Transmitter Links (STL)
- Studio-To-Studio Links (SSL)
- Audio Distribution
- Managing multiple incoming remotes at the studio
Multiple Backup Options
The Gateway has multiple levels of power, audio and network redundancy. The codec features dual Gigabit Ethernet ports, dual internal power supplies, automated audio silence detection and IP network backup solutions to ensure you’re always on the air.
Automated network failure detection provides auto switching to a backup IP connection. The codec can automatically switch between 4 backup audio sources to maintain program output at transmitter sites. Options include:
- Connection audio.
- Icecast streaming client.
- Audio file backup.
- Hardware bypass of audio inputs to outputs if power fails.
Specifications
General
- Dimensions: 19” x 1 3/4” x 11 13/16” [482mm (W) x 44.45mm (H) x 300mm (D)] excluding rear connectors
- Weight: 4 Kg /8 lb 13.100 oz
- Power: Dual AC 90-240V IEC power inlets; 2A 50-60 Hz
- Operating temp: 0°C to 45°C (32°F to 113°F)
- 10% ≥ RH ≤ 90% (0 to 45°C/32°F to 113°F), non-condensing
Algorithms
- IP Algorithms: Tieline Music, Tieline MusicPLUS, Opus, G.711, G.722, MPEG Layer 2, MPEG Layer-3 LC-AAC, HE-AAC, HE-AACv.2, AAC-LD, AAC-ELD, 16/24 bit aptX® Enhanced algorithm
- IP (uncompressed): Linear PCM16/24 bit 32kHz, 44.1kHz, 48kHz, 96kHz sampling
audio
- Robust dual DSP-based architecture designed for rock solid, mission critical STL audio
- Linear PCM16/24 bit 32kHz, 44.1kHz, 48kHz, 96kHz sampling
- Bidirectional mono, 3 mono, 6 mono, 8 mono and 16 mono connections and triple mono connections
- Distributing up to 16 bidirectional channels between two codecs
- Up to 8 bidirectional stereo connections.
- 2 stereo and 2 mono bidirectional connections
- 1 stereo and 4 mono bidirectional connections.
- Simultaneously distributing 1, 2, 3, 4, 6, 8, or 16 separate IP multi-unicast audio streams to up to 80 endpoints in total (Gateway-8 and Gateway-16)
- Broadcasting up to 8-16 separate IP audio streams in multicast server mode and distributing each of these streams to unlimited endpoints over compatible IP networks.
- Popular algorithms including LC-AAC, HE-AAC v1 and v2, AAC-LD, AAC-ELDv1 and v2, Opus, MPEG II, MPEG Layer-3, Tieline Music and MusicPLUS, G.722 and G.711.
- Internal SSD storage as standard
- Low-delay, cascade resilient aptX® Enhanced algorithm
- Optional WheatNet-IP card
- Up to 8 stereo or 16 mono WheatNet-IP audio channels in/out.
- Optional Dante card supports Dante stream management and discovery
- Input Processing: EQ and dynamic range compressor on all inputs
connectivity
- Dual Gigabit (10/100/1000) Ethernet ports support automatic switching for redundancy
- Dual AoIP ports for AES67, SMPTE ST 2110-30, ST 2022-7, Livewire+ and RAVENNA AoIP streaming
- Optional WheatNet-IP or Dante streaming via AoIP1
- Automated failover to backup connections.
- Support for up to 4 output audio source fail over options
- SmartStream PLUS dual redundant IP streaming
- Fuse-IP network bonding (data aggregation)
- SIP (SDP) compliant with EBU N/ACIP Tech 3326 and 3368 for interoperability with other codecs
- I3P EBU Tech 3347 integration for Intercom compatibility over IP
- Deterministic SIP answering and call routing: Configure up to 16 SIP accounts and connect up to 2 SIP interfaces
- Selectable fixed or automatic jitter buffer: 5 automated settings available to manage network connectivity and avoid dropouts (includes configurable min and max buffer settings).
- Configurable Forward Error Correction (FEC)
- Highly advanced error concealment strategies
- Real-time IP connection packet statistics
- Real-time IP link quality displayed.
- Support for Line Hunt dialing/answering and caller IDs using Tieline IP
operation
- Full hardware front panel interface including navigation, LCD display, PPM meters and dialing key pad
- User-friendly HTML5 Toolbox Web-GUI enables codec configuration and control remotely over WANs
- AES67 Web-GUI for configuration of AES67, ST 2110-30, ST 2022-7, Livewire+ and RAVENNA streams over an AES67 LAN
- HTTP Icecast or Shoutcast streaming
- Toolbox Scheduler supports loading/unloading, connecting and disconnecting programs
- Use the Cloud Codec Controller to configure & manage your entire codec network remotely
- Auto switching, dual internal AC power supplies
- IPv4 & IPv6 compatible and ready
- Asymmetric algorithmic encode/decode
- Integrated alarm management including automatic silence detection
- Low latency in-band RS-232 aux data channel
- Configurable software rules engine via web-GUI for Control Port (16 GPIOs), plus WheatNet-IP LIO compatibility.
- Upgrade firmware from SD card
- Automated firmware upgrade notifications via Web-GUI
- Support for multiple languages: English, Spanish, Portuguese and French*
- Backward compatible with all Tieline IP codecs
security
- User name and password protection of codec and Toolbox HTML5 Web-GUI
- Support for SSL Security Certificate installation
- SIP allow lists and deny lists allow filtering of SIP URIs and User Agents.
- Configuration of non-standard ports
- Firewall settings to enable or disable a range of firewall-related network services, or limit ping to only work in a local subnet
- Implementation of CSRF protection (Cross-Site Request Forgery)
- Cloud Codec Controller supports admin and user level access to codecs with password protection
* Denotes future release
